DEGSON FBUS22.5-05P
- 收藏
- 对比
FBUS22.5-05P
637-FBUS22.5-05P
端子板 - 隔板块
--
大陆
立即发货
DIN rail bus connector, Number of potentials: 5, pitch: 3.81 mm, Color: light gray, Contact surface : gold,Contact point gold plating,bus connector used to connect electronic module housing. Color: light gray.Compatible housing:FMEH-04P.
1最小包装量--
请发送询价，我们将立即回复。
在线咨询
FBUS22.5-05P详情
DEGSON FBUS22.5-05P重要参数规格及、参数值，及相似型号如下：
- 参数名参数值全选
- 参数名参数值全选
Number of potentials
5
Type of installation(din rail \ panel \ PCB soldering)
din rail
Pluggable or not
有
Environmental items(Compliant with REACH/RoHS )
有
Conductor material (copper / copper alloy)
Copper alloy
Contact point metal surface(conductor contact with wire)
gold
Contact zone metal surface(insert&pullout)
gold
Shell color
light gray
Insulation Materials (main class)
PA66
Insulating material group
I
Test standard (standard no.)
UL1059
Insert / pull out cycle
50
Rated current(B) UL
7A;150V
Ambient temperature (operation)
-40℃～ +105℃
Ambient temperature (storage/transportation)
-40℃～ +70℃
Packing unit
60
Products weight (without packaging)
4.58
Number of rows
1
螺距
3.81mm
Flammability rating
V0
