DEGSON FMEH-02P
- 收藏
- 对比
FMEH-02P
637-FMEH-02P
端子板 - 隔板块
--
大陆
立即发货
DIN rail housings, Complete housing with metal foot catch,tall design,with TBUS options, with vents,Width: 12.6mm,Color: light gray,material:PA66,Flammability rating :V0.
1最小包装量--
请发送询价，我们将立即回复。
在线咨询
FMEH-02P详情
DEGSON FMEH-02P重要参数规格及、参数值，及相似型号如下：
- 参数名参数值全选
- 参数名参数值全选
材料
PA66
Depth from top edge of DIN rail
107mm
Number of PCB holders
1
Installation location
Vertical (horizontal DIN rail)
PCBType of installation
Latching
IP class
IP20
Connection levels
3(Both sides)
with ventilation openings
有
Maximum connection
12（pitch 5.0mm）
Ambient temperature (assembly)
-5℃～ +100℃
Ambient temperature (operation)
-40℃～ +125℃
Ambient temperature (storage/transportation)
-40℃～ +55℃
PCB Plug
2EDGKF-5.0-02P-11-00A(H)
PCB Socket
2EDGLF-5.0-02P-11-00A(H)
The bus terminal
FBUS12.5-05P-11-00A(H)
Packing unit
32
Products weight (without packaging)
41.3
color
Light gray
width
12.6mm
length
99mm
高度
114mm
PCB thickness
1.5mm
Flammability rating
V0
