DEGSON SP-M12A-04P-FF-SH8002

Error-proof coding

A-Code

Overvoltage level

Ⅱ

Pollution level

3

Insertion and pullout cycle

≥ 100

Torque

0.4 Nm

Type of installation

Installation in front of the board

Flammability rating ,in line with UL94

V0

Contact Materials

CuZn

Material of contact surface

Au

Contact carrier material

PA

Coil material

Zinc alloy, nickel plated

Sealing material

Silicon

Standards/specifications

IEC 61076-2-101

Number of potentials

4

IP class

IP68

Ambient temperature

-40℃...105℃

Insulation resistance

≥ 100 MΩ

Rated current

4A

Connection method

Soldering pin
