Finder 39.11.8.230.0060

包装/外壳

Module

底架

DIN Rail

安装类型

DIN Rail

Coil Voltage AC

230 V

Contact Materials

Silver

Turn Off Delay Time

6 ms

Connections

Screw terminals

Switching current (max.)

6A

Nominal voltage

230V AC

Switching voltage (max.)

400V AC

Max. pick-up voltage

264V AC

Nominal voltage (details)

230V AC

Content

1pc(s)

Min. pick-up voltage

184V AC

Dimensions

6.2 x 90.7 x 87mm

Maximum Operating Temperature

+70°C

Minimum Operating Temperature

-40°C

Input Voltage Range

20.4 → 264V

Maximum Input Voltage

264V

Contact Current

6A

CoilResistance

-

With detachable clamps

无

Number of contacts as normally closed contact

0

Voltage type for actuating

AC

Degree of protection (IP)

IP20

Rated control supply voltage at AC 60 Hz

230 - 240

Number of contacts as normally open contact

0

Number of contacts as change-over contact

1

Type of electric connection

Screw connection

Nominal current

6

Rated control supply voltage at AC 50 Hz

230 - 240

RoHS

Compliant

系列

39 Series

终端

Screw

类型

39.11.8.230.0060

最高工作温度

70 °C

最小工作温度

-40 °C

深度

90.7 mm

输出量

EMR relays

投掷配置

单刀双掷

接通延迟时间

5 ms

触点额定电流

6 A

最小输入电压

230 V

端子类型

Screw

工作温度范围

-40 → +70°C

线圈电压

240V ac

线圈型

AC

切换电压

250 → 400V ac

接通时间

5ms

输入电流

4.3 mA

关断时间

6ms

开关电流

6 A

触点配置

单刀双掷

开关容量

1.5 kW

高度

90.7 mm

长度

87 mm

宽度

6.2 mm

达到SVHC

无SVHC

RoHS状态

符合RoHS标准

评级结果

IP20
