Fluke Electronics 2802385

质量

2.1kg

Voltage reading range DC (min.)

0.001mV

Voltage DC reading range (max.)

1000V

V AC reading range (min.)

0.001mV

V AC reading range (max.)

750V

Amperage reading range DC (min.)

0.001µA

A DC reading range (max.)

10A

A AC reading range (min.)

0.0001mA

Amperage reading range AC (max.)

10A

Reading range - resistance

0.001 Ω – 100MΩ

Frequency reading range

20 Hz -1MHz

DC resistance

10MΩ

AC resistance

1MΩ

Basic accuracy

0.015%

Measurement type (details)

真实有效值

Power supply (details)

230V AC

Calibrated to

Manufacturer's standards (no certificate)

Reading category

CAT I 1000 V,CAT II 600 V

Voltage metering

AC/DC

Current reading

AC/DC

Display

Digital

Display (counts)

200000

Dim

(L x W x H) 297 x 217 x 88 mm

Indication

Digital

Analogue bar graph display

无

Multiple display

有

Measuring range selection

Manual/automatic

Max. voltage measuring range, AC

750

Lowest resolution, AC voltage

0.001 mV

Max. voltage measuring range, DC

1000

Lowest resolution, DC voltage

0.001 mV

Max. current measuring range, AC

10

Lowest resolution, AC current

0.1 µA

Max. current measuring range, DC

10

Lowest resolution, DC current

0.001 µA

Max. resistance measuring range

100

Lowest resolution, resistance

0.001 Ohm

Temperature measurement

无

Resistance test/diode test

有

Capacitance measurement

无

Frequency measurement

有

With decibel measurement (dB)

有

Relative value measurement

有

Inductance measurement

无

With conductivity measurement

无

Data hold

有

Max. value storage

有

Min. value storage

有

Peak value memory

无

True RMS measurement

有

Duty cycle measurements

无

Measured value memory

无

Measuring circuit category

CAT II

Analogue bar graph display analogue/logarithmical

无

Milliohm measurement with 4 wire technique (Kelvin connection)

有

Temperature measurement RTD

无

Temperature measurement TC

无

Max. frequency measuring range

1000

Lowest resolution, frequency

0.01 Hz

Nominal test voltage 10 V

无

Nominal test voltage 50 V

无

Nominal test voltage 100 V

无

Nominal test voltage 250 V

无

Nominal test voltage 500 V

无

Nominal test voltage 1000 V

无

Cable length measurement

无

Cable symmetry testing for two wire connections a-b-E

无

Power and energy measurement

无

Harmonics analysis/power quality

无

Continuity test

有

Rotational speed measuring

无

Bluetooth interface

无

IR interface

无

Automatic circuit breaker

无

Max. voltage measuring circuit category

600

Explosion-tested version

无

With display backlight

有

Scaling bar graph lineair

无

Scaling bar graph logarithmic

无

类型

8808A 240V

界面

RS232

Frequency range

20 Hz - 100kHz

高度

88mm

宽度

217mm

长度

297mm
