Lapp 1123266-50

Sold per metre

无

Wire ID code

Black wires with white number printing (VDE 0293)

Certification marks

In accordance with VDE 0281 Part 14

Core layout

精细绞合

Package

有

No. of leads

2x

Min. temperature range (flexible installation)

-15°C

Max. temperature range (flexible installation)

+70°C

Min. temperature range (fixed installation)

-40°C

Max. temperature range (fixed installation)

+80°C

Nominal voltage U0

300V

Outside Ø

6.60mm

Nominal voltage

500V

Manufacturer part #

1123266-50

Cable features

Shielded,Halogen-free

Halogen-free

有

Cross section (each core)

1mm²

Factory colour

Grey

Cross section

2 x 1 mm²

Content

50m

Cable Types

ÖLFLEX® CLASSIC 135 CH

Bend radius (no. of ODs for fixed installation)

4

Bend radius (no. of ODs for flexible installation)

15

类型

ÖLFLEX CLASSIC 135 CH 2X1

Test voltage

Wire/Wire: 4000 V<br>Wire/shield: 2000V
