Lapp 2170284-100

Specification

CAT 5e

Cable Types

UNITRONIC® EtherLine®

No. of leads

4x

Cross section (each core)

0.12mm²

Cross section

2 x 2 x 0.12 mm²

Cable features

Halogen-free,Flame-retardant,PUR coating,Simplex

Outside Ø

5.80mm

Factory colour

Blue

Max. frequency

100MHz

Content

100m

AWG max.

26

Package

有

Sold per metre

无

Manufacturer part #

2170284-100

Insulation Materials

Polyurethane

Min. temperature range (flexible installation)

-5°C

Max. temperature range (flexible installation)

+50°C

Min. temperature range (fixed installation)

-30°C

Max. temperature range (fixed installation)

+80°C

Twisted pair cabling (part 1)

Yes (1)

类型

ETHERLINE P FLEX CAT5E 2X2XAWG26

屏蔽/屏蔽

SF/UTP

Temperature range

-40 - +70°C
