Lapp 21880-1

Bend radius (no. of ODs for flexible installation)

15

Bend radius (no. of ODs for fixed installation)

4

Cable Types

ROBUST 210

Content

每米售价

Cross section

2 x 0.5 mm² w/o gn/ge

Factory colour

Black

Cross section (each core)

0.50mm²

Suited for cable carriers

无

Halogen-free

有

Cable features

UV-resistant,Halogen-free

Manufacturer part #

21880-1

Nominal voltage

500V

Outside Ø

4.90mm

Max. length sold by the metre

500m

Nominal voltage U0

300V

Max. temperature range (fixed installation)

+80°C

Min. temperature range (fixed installation)

-50°C

Max. temperature range (flexible installation)

+80°C

Min. temperature range (flexible installation)

-40°C

Number-coded

有

No. of leads

2x

Package

无

Core layout

Finely stranded according to VDE 0295, Class 5/IEC 60228 Class5

Nominal voltage (details)

300/500V

Certification marks

In accordance with: Wires: VDE 0245/0250/0281, sheath according to VDE 0250/0281.

Wire ID code

Black wires with white number printing (VDE 0293)

Sold per metre

有

类型

ÖLFLEX® ROBUST 210 2X0,5

Temperature range

Moving: -40 - +80 °C, when fixed : -50 - +80°C

Bend radius

For flexible use: 15 x external dia. when laid fixed: 4 x external dia.
