Lapp 4512382S

Nominal voltage

500V

Cable Types

X05V-K

Content

每米售价

Cross section

1 x 0.75 mm²

Factory colour

Orange,Black

Cross section (each core)

0.75mm²

Halogen-free

无

Insulation Materials

PVC

Cable features

Flame-retardant,Flexible

Manufacturer part #

4512382S

Material (details)

Bare copper, finely stranded Class 5

AWG max.

20

Outside Ø

2.40mm

Max. length sold by the metre

250m

Nominal voltage U0

300V

Max. temperature range (fixed installation)

+80°C

Min. temperature range (fixed installation)

-30°C

Max. temperature range (flexible installation)

+70°C

Min. temperature range (flexible installation)

+5°C

No. of leads

1x

Package

无

Core layout

finely stranded according to VDE 0295 ·<br>Class 5 / IEC 60228 Cl. 5

Nominal voltage (details)

300/500V

Certification marks

VDE 0281 · HD 21

Current load capacity

Current capacity to VDE 0298 Part 4.

RoHS-compliant

有

Sold per metre

有

类型

X05V-K

Temperature range

-30 - +80°C

标准

Flame-resistant according to IEC 60332-1-2

Test voltage

2000V
