Lapp 4726013K

Nominal voltage

750V

Cable Types

H07Z-K

Content

600m

Cross section

1 x 4 mm²

Factory colour

Black

Cross section (each core)

4mm²

Halogen-free

有

Cable features

Flame-retardant,Halogen-free,Harmonised,Flexible

Manufacturer part #

4726013K

Outside Ø

4.90mm

Nominal voltage U0

450V

Max. temperature range (fixed installation)

+90°C

Min. temperature range (fixed installation)

-15°C

Max. temperature range (flexible installation)

+90°C

Min. temperature range (flexible installation)

-15°C

No. of leads

1x

Package

有

Core layout

Fine strand according to VDE 0295, Class 5 / IEC 60228 Cl. 5

Certification marks

According to VDE 0282 Part 9 / HD 22.9 S1

Sold per metre

无

类型

H07Z-K 90°C EMBOSS 1X4 BK

Test voltage

2500V
