Ruichi EM-717

Name: EM-717
Brand: Ruichi
SKU: 3465-EM-717
Availability: InStock
Rating: 5 (1 reviews)

收藏
对比

型号

EM-717

品牌

Ruichi

utmel 编号

3465-EM-717

商品类别

接口 - 模块

封装

交货地

大陆

交期（工作日）

立即发货

ROHS

ECAD

简介

RUICHI EM-717 stepper motor driver, green is a structurally and functionally complete radio-electronic device or radio-electronic functional unit, designed in modular or bus-modular execution with ensuring constructive, electrical, information compatibility and interchangeability.

起订量

1最小包装量--

添加到询价列表

EM-717 Ruichi RUICHI EM-717 stepper motor driver, green is a structurally and functionally complete radio-electronic device or radio-electronic functional unit, designed in modular or bus-modular execution with ensuring constructive, electrical, information compatibility and interchangeability.

请发送询价，我们将立即回复。

库存:

请发送询价，我们将立即回复。

* 联系人姓名

* 电话

* 邮箱

* 公司名称

* 数量

在线咨询

EM-717详情

技术参数

Ruichi EM-717重要参数规格及、参数值，及相似型号如下：

参数名

参数值

全选
参数名

参数值

全选
质量

2 g
Chip

A4988
Description

Stepper motor driver (green)
Protection

from overheating and overload, from short circuit; lockout upon decreased Usupply
Gross weight

6.20
Transport packaging size/quantity

42*28*23.5/500
Application area

for 5 V bipolar stepper motors
Output voltage

logical levels 3.3; 5.0 V
Operating mode

1; 1/2; 1/4; 1/8; 1/8; 1/16 microstep
Output current

1 A - without heatsink; 2 A - with heatsink (adjustable)
Input voltage

8…35 V
Module type

Stepper motor driver (green)
