Siemens 3RT10642NP36

安装类型

Chassis Mount, DIN Rail

厂商

Siemens

Package

Bulk

Product Status

活跃

Contact Materials

-

CoilResistance

-

No. of pins

3-pin

Nominal voltage

1000V AC

Connections

Terminal strip

Min. temperature

-25°C

Max. temperature

+60°C

Dim

(W x H x D) 145 x 210 x 202 mm

Content

1pc(s)

RoHS-compliant

有

Rated operation power at AC-3, 400 V

110kW

Number of normally open contacts as main contact

3

Number of auxiliary contacts as normally open contact

2

Number of auxiliary contacts as normally closed contact

2

Rated operation current Ie at AC-3, 400 V

225A

Rated operation current Ie at AC-1, 400 V

275A

Rated operation current Ie at AC-4, 400 V

195A

Rated operation power at AC-4, 400 V

110kW

Rated control supply voltage at AC 50 Hz

200 - 277

Type of electrical connection of main circuit

Rail connection

Modular version

有

Rated operation power NEMA

110.325

Rated control supply voltage at AC 60 Hz

200 - 277

Voltage type for actuating

AC/DC

Number of normally closed contacts as main contact

0

Rated control supply voltage at DC

200 - 277

系列

SIRIUS

操作温度

-25°C ~ 60°C

类型

S10

Contact type

3 makers

深度

202mm

终端样式

弹簧端子

耐用性

1000 0000

触点形式

3PST-NO (3 Form A)

运行时间

80 ms

线圈电压

200 ~ 277VAC/DC

切换电压

1000VAC - Max

发布时间

100 ms

必须运行电压

-

触点额定值(电流)

225 A

线圈功率

580W

必须释放电压

-

IP rating

IP00

宽度

145mm

高度

210mm
