Siemens 3RT20182XF410LA2

安装类型

Chassis Mount, DIN Rail

厂商

Siemens

Package

Bulk

Product Status

活跃

Contact Materials

-

CoilResistance

-

No. of pins

3-pin

Auxiliary contact type

1 maker

Nominal voltage

690V AC

Connections

Spring-loaded connector

Dim

(W x H) 45 mm x 70 mm

Content

1pc(s)

RoHS-compliant

有

Rated operation power at AC-3, 400 V

7.5kW

Number of normally open contacts as main contact

3

Number of normally closed contacts as main contact

0

Number of auxiliary contacts as normally open contact

1

Rated operation current Ie at AC-3, 400 V

16A

Rated operation current Ie at AC-1, 400 V

22A

Rated operation current Ie at AC-4, 400 V

11.5A

Rated operation power at AC-4, 400 V

5.5kW

Type of electrical connection of main circuit

弹簧夹连接

Modular version

有

Rated operation power NEMA

7.355

Voltage type for actuating

DC

Rated control supply voltage at DC

72 - 125

系列

SIRIUS

操作温度

-40°C ~ 70°C

类型

S00

Contact type

3 makers

终端样式

弹簧端子

耐用性

3000 0000

触点形式

3PST-NO (3 Form A)

运行时间

70 ms

线圈电压

72 ~ 125VDC

切换电压

690VAC - Max

发布时间

45 ms

必须运行电压

-

触点额定值(电流)

16 A

线圈功率

4.5W

必须释放电压

-

宽度

45mm

高度

70mm
