turck RI-10S6S-2B1024-12M23

Housing material

Die-cast zinc

质量

402 g

EAN

4047101262063

eCl@ss-Code (V5.1.4)

27270502 -/- Encoder, incremental

Customs tariff number

90318080000

Country of origin

DE

Encoder line

Industrial-Line

Shaft Type

Solid shaft

Shaft diameter D (mm)

6

Flange type

Synchro flange

Resolution incremental

1024  ppr

Ambient temperature

-40…+85 °C

Protection class shaft

IP67

Protection class

IP67

Manufacturer ID

1544841

Output type

Incremental

Output function

Push-Pull/HTL, with inverted signals

Flange diameter

Ø  58 mm

Operating voltage

10…30 VDC

Electrical connection

Connector
