turck RI-10S6S9-2K1024-CA1M

Housing material

Die-cast zinc

eCl@ss-Code (V5.1.4)

27270502 -/- Encoder, incremental

Encoder line

Industrial-Line

Shaft Type

Solid shaft

Shaft diameter D (mm)

6

Flange type

Synchro flange

Resolution incremental

1024  ppr

Ambient temperature

-40…+85 °C

Protection class shaft

IP67

Protection class

IP67

Manufacturer ID

200005575

Output type

Incremental

Output function

Push-Pull 7272, with inverted signals

Flange diameter

Ø  50.8 mm

Operating voltage

5…30 VDC

Electrical connection

Cable
