wago 243-9294/995-020

质量

0.8g

Safety management note

NOTICE: Observe installation and safety instructions!Only to be used by electricians!Do not work under voltage/load!Use only for proper use!Observe national regulations/standards/guidelines!Observe technical specifications for the products!Observe the number of permissible potentials!Do not use damaged/dirty components!Observe conductor types, cross-sections and strip lengths!Insert conductor until it hits the product‘s backstop!Use original accessories!To be sold only with installation instructions!

Clamping units

4

Total number of potentials

1

Number of connection types

1

Note (material data)

Information on material specifications can be found here

Fire load

0.012MJ

Ambient temperature (operation)

+60 °C

ETIM 9.0

EC000446

ETIM 8.0

EC000446

ECCN

NO US CLASSIFICATION

PU (SPU)

360 (20) pcs

Packaging type

Blister foil

Country of origin

DE

GTIN

4066966002003

Customs tariff number

85369010000

RoHS Compliance Status

Compliant,No Exemption

Ratings per

EN 60664

Nominal voltage (II/2)

100V

Rated surge voltage (II/2)

1.5kV

Legend (ratings)

(II / 2) ? Overvoltage category II / Pollution degree 2

Connection technology

PUSH WIRE?

Actuation type

Push-in

Connectable conductor materials

Copper

Solid conductor

22 … 20 AWG

Conductor diameter (note)

When using conductors of the same diameter, 0.5 mm (24 AWG) or 1 mm (18 AWG) diameters are also possible.

Strip length

5 … 6 mm / 0.2 … 0.24 inches

Wiring direction

Side-entry wiring

颜色

dark gray

深度

10 mm / 0.394 inches

Number of levels

1

Rated current

6A

Conductor diameter

0.6 … 0.8 mm / 22 … 20 AWG

宽度

10 mm / 0.394 inches

高度

6.8 mm / 0.268 inches
