Lapp 44420135

Number of pins

17

Content

20pc(s)

Total no. of pins

17

Industrial packaging

有

Leading contact (PE)

无

Connections

Crimp

Manufacturer part #

44420135

Connector cross section

0.08 - 0.56mm²

Contact insert without contacts

有

Diameter plug-in contact

1

Material connector insert

Thermoplastic

Rated current In

4

Ambient temperature

-25 - 125

Rated surge voltage

0.8

Overvoltage category

III

Pollution degree

3

Type of electric connection

压接

With wire protection

有

Connectable conductor cross section fine-strand without cable end sleeve

0.08 - 0.56

Connectable conductor cross section fine-strand with cable end sleeve

0.08 - 0.56

Connectable conductor cross section solid-core

0.08 - 0.56

Connectable conductor cross section multi-wired

0.08 - 0.56

Material of contact surface

Gold

Material contact

Brass

Inflammability class of insulation material according to with UL94

V0

With protective conductor

无

Connector type

Socket

类型

P-part, left-hand

Contact type

Bus

Number of poles

17

Test current

4A

Rated voltage

100V

特征

Left-hand
