DEGSON Single relay-DRPE-2C-L-A220-02A(H)

Ambient temperature (operation)

-40℃～+70℃

Ambient temperature (storage/transportation)

-40℃～+70℃

environment humidity

35%~85%RH

Rated input voltage UN

220VAC

Products weight (without packaging)

40

Packing unit

20

Relay socket

DPYF08A1-E3-02A(H)

Installation location

Arbitrary

Operation mode

100% work factor

Test voltage PDT/PDT

1000VAC/1min

Test voltage relay coil/relay contact

1500VAC/1min

Overvoltage category

Ⅲ

Pollution level

3

Protection level

IP50

Standards/Regulations

IEC 61810-1 IEC 60664

ElectricalLife

>1×105

Vibration resistant

10-55Hz

Shock proof

10G

Withstand voltage (between contacts of the same pole)

1000VAC/1min

Withstand voltage (between different pole contacts)

1500VAC/1min

Withstand voltage (between coil and contact)

1500VAC/1min

Maximum switching frequency (rated load)

1800 times/h

Maximum switching frequency (mechanical)

18000 times/h

Reset time

<20ms

Action time

<20ms

Contact Materials

Ag alloy

Contact mechanism

single

Contact composition

2C

Maximum contact current

5A

Maximum contact voltage

AC240V DC28V

Power consumption under rated conditions

1.2VA

Maximum allowable voltage

1.1

Reset voltage

≥30%

CoilResistance

640Ω

Typical input current under UN

120mA

Contact resistance

≤100mΩ

Insulation resistance

≥100MΩ

Mechanical life

>1×107

insulation

Basic isolation

Operating voltage

≤80%

高度

36.5mm

width

21.5mm

length

27.2mm
