MEAN WELL PWM-120-24BLE

质量

970g

Dim

(L x W x H) 191 x 63 x 37.5 mm

Factory colour

Anthracite/black

Test mark

CE · MM · SELV

Max. output current

5A

Output current (max.) - rounded

5A

Protection class

II

Power range

120 W (max)

Connections

开口电缆

LED driver features

dimmable,Suitable for flammable surfaces,Approved for use on furniture,Outdoor,PFC circuit,Surge protection,Overvoltage

Input voltage (max.)

305V AC,431V DC

Min. input voltage

90V AC,127V DC

Output voltage (max.)

24V DC

Max. power

120W

No. of inputs

1x

No. of outputs

1x

Max. temperature

+90°C

Min. temperature

-25°C

类型

Constant voltage

Operating voltage

230V AC,115V AC

IP rating

IP67

高度

37.5mm

长度

191mm

宽度

63mm
